Motoway 2009 Catalog

Provide the BEST Service

=======================================================

AC-001 Cigar Lighter Outlet

For mounting on the motorcycle handlebar. External power supply for 12V consum such as Navigation device, mobile phones, mp3 players, compressor, etc. Delivery: Outlet with a rubber cover (splash-proof) Handlebar for Customs and metric handlebars Cable (length 90 cm) Backup (10 A) two cable ties

=======================================================

ML-001 Mini Lifter

Tired of using a car jack? Try our Mini Lifter. For use with table lift for easy raising and lowering of your motorcycle while on lift.

Has a lifting capacity of 770lbs with a lifting range of up to 12". Drops down to 3.5" to allow raising of lowered bikes.

=======================================================

WB-001 Wheel Balance Stand includes 3/4” & 1” shafts

=======================================================

HT001 Rocker Box Cover Ratcheting Bolt Wrench

This reversible ratcheting box wrench is used on all Harley-Davidson® Evolution® motor rocker box covers. This 9-3/4" long chrome plated wrench consists of a 1/4" drive with 3/16" replaceable Allen bit and vinyl grip.

Contains a replaceable bit. If bits are damaged or worn out during use, they can be easily replaced.

The wrench has a reversible ratcheting action so the socket head cap screw can be ratcheted in or out. When using a conventional wrench, installers may unscrew the bolt up to the frame. Without the ability to reverse, the bolt may get lodged in that position.

The wrench is low profile to allow clearance between the frame and the engine. The long handle is for increased reach. The comfortable ergonomic rubber grip will not scratch chrome while working on the rocker box cover.

=======================================================

HT002 Lower Rocker Box Wrench 7/16" 25MM for EvolutionR

This extra long reversible ratcheting box wrench is used to install/remove the lower rocker box on Harley-DavidsonR motorcycles with EvolutionR engines (1994–1999).

A special 7/16" socket 25MM protrudes out of the wrench to reach the application. Vinyl grip provides a comfortable ergonomic grip and prevents the wrench from scratching or marring the bike.

=======================================================

HT003 Exhaust Bracket Wrench

This reversible ratcheting wrench is used to remove and install the front exhaust bracket on

Harley-Davidson® Dyna® model Twin Cams® from 1999 to present.

This single-end, flat wrench is 9-3/4" long with a removable/replaceable shortened T-27 TORX® bit. Low profile design allows for easy access to the exhaust bracket in between the frame and the engine. Vinyl grip provides a comfortable ergonomic grip and prevents the wrench from scratching or marring the bike. Retaining ring allows for the bit to be removed and replaced when damaged.

=======================================================

HT004 Lower Rocker Box Wrench 7/16" 35MM for EvolutionR

This extra long reversible ratcheting box wrench is used to install/remove the lower rocker box on Harley-DavidsonR motorcycles with EvolutionR engines (1994–1999).

A special 7/16" socket 35MM protrudes out of the wrench to reach the application. Vinyl grip provides a comfortable ergonomic grip and prevents the wrench from scratching or marring the bike.

=======================================================

HT005 Oil Pressure Indicator Lamp Sending Unit Wrench

These reversible ratcheting wrenches are used to remove and install the oil pressure indicator lamp sending unit on Harley-Davidson® FL Touring® motorcycles (1999 and up).

Special low profile of 15/16" wheels allow access to remove and install sending unit without further disassembly. Vinyl grip provides a comfortable ergonomic grip and prevents the wrench from scratching or marring the bike.

=======================================================

HT006 Oil Pressure Indicator Gauge Sending Unit Wrench

These reversible ratcheting wrenches are used to remove and install the oil pressure indicator gauge sending unit on Harley-Davidson® FL Touring® motorcycles (1999 and up).

Special low profile of 1-1/16" wheels allow access to remove and install sending unit without further disassembly. Vinyl grip provides a comfortable ergonomic grip and prevents the wrench from scratching or marring the bike.

=======================================================

HT007 Rear Axle 36mm Nut Ratchet Wrench

This reversible ratcheting wrench is used to remove and install the rear axle nut on Harley-Davidson® FL Touring® models with 36mm axle nuts.

This extra long wrench contains a 1/2" square drive for a torque wrench. Insert torque wrench at a 90° angle for proper torque reading.

A custom 36mm double hexagon Torque Grip® wheel allows access to reach the application without the removal of exhaust. Loosening and tightening of this nut is a necessary procedure when tightening a drive belt or changing a rear tire. Vinyl grip provides a comfortable ergonomic grip and prevents the wrench from scratching or marring the bike.

=======================================================

HT008 24-Tooth Crankshaft Rotating Wrench

Used for rotation of the crankshaft on all 24-spline (2006 Harley-Davidson® Dyna®) motors, and to check engine timing and parts clearance.

FEATURES & BENEFITS

Ratcheting action to check engine timing and parts clearance faster!

Custom design fits perfectly on the crankshafts of 2006 Dyna® models.

Heat-treated and chrome-plated.

Ergonomic E-Z Grip handle allows more turning power with less fatigue to the hand.

=======================================================

HT009 Magnetic Speedometer Sending Unit Wrench

This extra long reversible offset ratcheting wrench is used to remove and install magnetic speedometer sending units for Harley-Davidson® Sportster® motorcycles and other Harley-Davidson® applications with magnetic speedometer sending units.

This single-end wrench contains a magnetic 1/4" drive and a comfortable vinyl grip.

Shortened 3/16" ball end hex bit allows access to remove and install sending units

without further disassembly.

Magnetic drive allows bit to be replaced when worn or damaged.

Vinyl grip provides a comfortable ergonomic grip and prevents the wrench from

scratching or marring the bike.

=======================================================

HT010 Intake Manifold Wrench

This reversible ratcheting box wrench is used on Big Twin® engines to install and remove intake manifold socket head cap screws. The wrench consists of a vinyl grip and a 1/4" ball-end Allen bit.

=======================================================
